Caofen F80 Electric Motorbike - Street Sport Version

CAOFEN F80: Street Sport Version Electric Motocycle

Introducing the CAOFEN F80 Street Sport Version E Motorcycle, a versatile and powerful off-road companion for your adventures. The Caofen F80 Street Sport Version E Motorcycle is an exceptional sports e-Motorcycle that is built to withstand the test of time. Boasting an AlMg alloy frame construction, a high charge and discharge rate battery, and an 8KW motor, this Motorcycle is engineered to conquer the toughest terrains and climates.

Original Factory Version with Upgraded Battery

Caofen is the first electric Motorcycle that introduced a solution for durability of its battery. As you are aware, the battery of the Motorcycle is the one subjected to the highest abuse because of the high-power demand. This generates heat which is the slow killer of the Lithium batteries. Caofen implemented high discharge rate batteries, but also submerged them in dielectric fluid that constantly cools them. Another advantage are two safety features usually available for high end motorcycles. There is an electronic ABS brake system that can be engaged and disengaged by a switch. The same applies for the regenerative braking system.

Intelligent Electric Energy Recovery
Electrically Controlled Lock

Patented Battery Technology

The Caofen F80 E Bike / E Motorcycle has one of the most technologically advanced batteries available today.

The magnesium alloy casing houses automotive grade 21700 ternary lithium cells, an advanced BMS with CAN communication, a patented auxiliary heating system and a unique flame-retardant oil cooling system

This technology provides far greater battery stability, improving performance allowing you to ride faster for longer. The operating temperature range of the battery is extended from -40 Celsius to 60 Celsius and allows for faster more efficient charging.

Advantages

Battery can be charged in approximately half the time of a standard lithium battery.
Battery life is approx. 1.5 times (1200 cycles) that of a standard lithium battery.
Consistent high performance due to outstanding temperature stability.
Engineered for use in extreme conditions to IP67 waterproof standards.

Liquid Submerged Batteries

Caofen stands as a pioneer in the world of commuter electric motorcycles, distinguished by its innovative unibody frame and an ingenious cooling system that submerges the batteries in oil. With a dedicated team specializing in alloy material application, core component manufacturing, and electric motorization, Caofen has set the standard for safety and reliability within its category.

Caofen have applied a patented immersion cooling battery system to their motorcycle, which results in 8 times the thermal balance and only 50% of normal temperature rise. The temperature control system allows you to ride freely in any case even in -40 degrees environment. The temperature improves work efficiency while maintaining a balance.

As you are aware, the battery of the dirt bike is the one subjected to the highest abuse because of the high-power demand. This generates heat which is the slow killer of the Lithium batteries. Caofen implemented high discharge rate batteries, but also submerged them in dielectric fluid that constantly cools them. Another advantage are two safety features usually available for high end motorcycles. There is an electronic ABS brake system that can be engaged and disengaged by a switch. The same applies for the regenerative braking system.

Lightweight and Durable

This off-road powerhouse is built for agility and durability. Despite its robust features, it's surprisingly lightweight, weighing only 135 lbs without the battery. The CAOFEN F80 can handle a maximum single load of 220 lbs, making it ideal for both solo adventurers and those who want to share the thrill of off-road riding. The total weight varies depending on your choice of battery, with the 32Ah battery option adding 44 lbs and the 60Ah battery adding 60 lbs to the overall weight.

New Upgraded Powerful Battery

The CAOFEN F80 offers two battery options – 32Ah (2304WH) & 60Ah (4320WH). These batteries provide exceptional range, allowing you to explore further on a single charge.

It comes with an upgraded battery size 72V/32AH battery with total capacity of 2.3KWH. The longevity of lithium-ion batteries greatly depends on the management of excessive heat. The Caofen F80B distinguishes itself as the first electric dirt bike to feature a patented immersion cooling battery system.

With the 32Ah battery, you can achieve an average range of 30 miles at 40MPH, or up to 50 miles at 20MPH on a single charge. Opt for the 60Ah battery, and you'll enjoy even more extended adventures with an average range of 75 miles at 40MPH and an incredible 112 miles at 20MPH.

Powerful Motor

The CAOFEN F80 Street SPORTS Version E Motorcycle is equipped with a high-performance motor that can reach a maximum speed of 52 mph. Its chain drive system delivers power efficiently to the wheels, ensuring an exhilarating riding experience. Additionally, its wading depth of 2 feet means you can confidently cross shallow water obstacles.

Advanced Power System

The CAOFEN F80 offers flexibility with two battery options and impressive charging capabilities. The 32Ah battery can be charged from 0 to 100% in just 2 hours, while the 60Ah battery requires only 4 hours for a full charge. The charger accepts standard 110V input, making recharging a breeze. The power system's rated power ranges from 6 Kw with the 32Ah battery to 8 Kw with the 60Ah battery, with max peak power reaching up to 10 Kw.

Suspension and Traction

Front shock absorption with a 10.5" travel ensures a smooth ride over rough terrain, while a 50% slope gradeability means you can conquer steep inclines with ease. The front and rear wheels are equipped with high-quality tires designed for dirt and adventure riding.

Robust Frame and Construction

The High Strength Alloy Integrated Frame of the CAOFEN F80 Street Sport Version E-Motorcycle is designed with a unique and innovative feature: it is a one-piece frame with no welds. This engineering concept eliminates the need for traditional welding joints, providing several advantages.

First, the absence of welds reduces the risk of structural weakness or fatigue at the weld points, which can be a common concern with traditional bicycle frames. This results in a more durable and reliable frame that can withstand the stresses and strains of regular use, especially in off-road or sport riding scenarios.

Embark on the adventure of a lifetime with the CAOFEN F80 Street Sport Version motorcycle. Its exceptional specifications and durable construction make it the perfect choice for riders who crave off-road excitement. Whether you're navigating trails, conquering challenging terrain, or simply enjoying the thrill of the open road, the CAOFEN F80 is your trusted companion. Order yours today and experience the freedom of off-road riding like never before.

Street Legal Electric Motorcycle

Experience the freedom of CAOFEN electric Motorcycles – crafted to be street legal in over 50 states across the USA. These bikes seamlessly blend power and compliance, offering a thrilling and roadworthy riding experience. However, please ensure to check the local regulations and requirements in your specific area to confirm the street legality of CAOFEN bikes in your locality. Ride with confidence, knowing that CAOFEN has your street-legal needs covered.
